51 |
GASKET, Intake |
|
51A |
Gasket-Intake |
|
93 |
Bushing-Throttle Shaft |
|
94 |
Kit-Idle Mixture-(Walbro) |
|
94A |
KIT, Idle Mixture-(Nikki) |
|
95 |
Screw-(Throttle Valve) (Walbro) |
|
95A |
SCREW-(Throttle Valve) (Nikki)-Used Before Code Date 15113000 |
|
98 |
Kit-Idle Speed-(Walbro) |
|
98A |
KIT, Idle Speed-(Nikki)-Used Before Code Date 15113000 |
|
104 |
Pin-Float Hinge-(Walbro) |
|
104A |
PIN, Float Hinge-(Nikki)-Used Before Code Date 15113000 |
|
105 |
Valve-Float Needle-(Walbro) |
|
105A |
VALVE, Float Needle-(Nikki)-Used Before Code Date 15113000 |
|
106 |
Seat-Inlet-(Gravity Feed) |
|
106 |
Seat-Inlet-(Pump Feed) |
|
108 |
Valve-Choke-(Walbro) |
|
108A |
Valve-Choke-(Nikki)-Used Before Code Date 15113000 |
|
117A |
Jet-Main-(Standard)-Used Before Code Date 08051400 |
|
117A |
Jet-Main-(Standard)-Used After Code Date 08051300-Used Before Code Date 15113000 |
|
118A |
Jet-Main-(High Altitude)-Used After Code Date 08051300-Used Before Code Date 15113000 |
|
118A |
Jet-Main-(High Altitude)-Used Before Code Date 08051400 |
|
121 |
Kit-Carburetor Overhaul-(Walbro Carburetor) |
|
121A |
KIT, Carburetor Overhaul-(Nikki Carburetor)-Used Before Code Date 15113000 |
|
125A |
Carburetor-(Nikki)-Used After Code Date 08051300-Used Before Code Date 15113000 |
|
125A |
Carburetor-Used Before Code Date 08051400 |
|
127 |
Plug-Welch |
|
127A |
PLUG, Welch |
|
130 |
Valve-Throttle-(Walbro) |
|
130A |
Valve-Throttle-(Nikki)-Used Before Code Date 15113000 |
|
131 |
Kit-Throttle Shaft-(Walbro) |
|
131A |
Kit-Throttle Shaft-(Nikki)-Used Before Code Date 15113000 |
|
133 |
Float-Carburetor-(Walbro) |
|
133A |
FLOAT, Carburetor-(Nikki)-Used Before Code Date 15113000 |
|
135 |
Tube-Fuel Transfer-(Pump Feed)(Does Not Include Jet) |
|
135 |
Tube-Fuel Transfer-(Nikki)(Gravity Feed)(Does Not Include Jet) |
|
137 |
Gasket-Float Bowl-(Walbro) |
|
137A |
GASKET, Float Bowl-(Nikki)-Used Before Code Date 15113000 |
|
141 |
Kit-Choke Shaft |
|
141A |
Kit-Choke Shaft-Used Before Code Date 15113000 |
|
142 |
Nozzle-Carburetor |
|
187 |
LINE, Fuel-(15\" Long)(Cut to Required Length) |
|
187A |
Line-Fuel-(Formed)(21\" Long)(Cut to Required Length) |
|
187B |
LINE, Fuel-(Formed)(10-1/4\" Long)(Cut to Required Length) |
|
217 |
SPRING, Choke Return-Used Before Code Date 15113000 |
|
240 |
FILTER, Fuel-(White, 75 Microns) |
|
276 |
Washer-Sealing-(Walbro) |
|
276A |
WASHER, Sealing-(Walbro)-Used Before Code Date 15113000 |
|
385 |
Screw-(Fuel Pump) |
|
385A |
Screw-(Fuel Pump) |
|
387 |
Pump-Fuel-(Includes Mounting Bracket)-Used Before Code Date 08082500 |
|
387A |
PUMP, Fuel-Used After Code Date 08082400 |
|
601 |
CLAMP, Hose-(Green) |
|
601 |
CLAMP, Hose-(Black) |
|
617 |
SEAL, O-Ring-(Intake Manifold) |
|
633 |
SEAL, Choke/Throttle Shaft-(Nikki)-Used Before Code Date 15113000 |
|
633B |
SEAL, Choke/Throttle Shaft-(Nikki)-Used Before Code Date 15113000 |
|
634A |
Spring/Seal Assembly-(Walbro) |
|
634B |
Spring/Seal Assembly-(Nikki) |
|
692 |
Spring-Detent |
|
773 |
RETAINER |
|
788 |
Bracket-Fuel Pump |
|
918 |
Hose-Vacuum-(Formed)(14 Inches Long)(Cut To Required Length) |
|
947 |
Solenoid-Fuel-(Walbro) |
|
947A |
Solenoid-Fuel-(Nikki)-Used Before Code Date 15113000 |
|
950 |
SCREW, Float Bowl-(Bottom Of Bowl) |
|
951 |
KIT, Choke Shaft |
|
958 |
VALVE, Fuel Shut Off(PLT) |
|
975 |
Bowl-Float-(Walbro) |
|
975A |
BOWL, Float-(Nikki)-Used Before Code Date 15113000 |
|
987 |
Seal-Throttle Shaft |
|
1091 |
Cap-Limiter |
|
1127 |
SCREW, Float Bowl-(Float Bowl to Carburetor Body) |
|
1139 |
WASHER-(Fuel Pump Bracket) |
|
1146 |
SCREW-(Choke Shaft) |
|
1266 |
SEAL, O-Ring-(Intake Elbow) |
|
1266A |
Seal-O Ring-(Intake Elbow) |
